The Bosch GCM12SD is a 12" Dual-Bevel Glide miter saw that features a smooth cutting motion, accurate performance and a space-saving design of the Bosch-exclusive Axial-Glide system. Pre-aligned Squarelock fences help the saw maintain precision throughout its life. A soft-grip ambidextrous handle along with a combination dust chute and vacuum adaptor add to user comfort. The saw also offers a large cutting capacity, easy-to-read bevel and miter scales with detents at common angles, and easy-access upfront controls.
Integrated expanding base extensions: 60% more left-to-right material support than leading competitor - 40” left to right
Large easy-to-read uniform bevel & stainless steel miter scales: 52° left/60° right miter capacity; 47° left/47° right bevel capacity with marked detents and roof pitch angles
Adjustable miter detents: detents at 0°, 15°, 31.6°, 22.5°, 45°, 60° right super-accurate and durable design
Push-button miter Detent override - easy-to-access thumb actuated control right up front for fine miter angle adjustment
Bevel detents: 0, 33.9°, 45° left/right for accurate cuts
Category best 90% dust collection - optimized for cutting 2x material with a vacuum
Ergonomic ambidextrous trigger handle with soft grip - large form fitting ergonomic handle provides comfort for all-day use
Includes: (1) 12” 60T Blade, (1) Material Clamp, (1) Dust Bag
Specifications:
15A motor
48° left and 48° right Bevel Angle Range
0°, 33.9°, 45° Left/Right Bevel Stops
12.0 Blade Diameter
Dust Collection: Yes
32.375” Length
52° Left, 60° Right Miter Angle Range
0°, 15°, 22.5°, 31.6°, 45° (Left/Right) Miter Detents
0°, 15°, 22.5,° 31.6°, 45° (Left/Right), 60° (Right) Miter Positive Stops
3,800 No Load RPM
120 Volts
26.5” Width
65.0 lbs
